Conductive

Tubular Heaters

TUTCO’s versatile Tubular Heaters are custom-formed in a wide variety of shapes to correspond to your requirements. Incoloy®, stainless steel or steel sheath materials are available, as well as a large selection of termination styles. Magnesium oxide (MgO) insulation ensures superior heat transfer, and the resistance wire is precision-wound for long heater life.

Tubular heaters can be used in almost any application. Straight Tubulars can be clamped to metal surfaces or inserted in machined grooves for conductive heat transfer. Or use a formed Tubular to provide consistent heat in any type of special application.

Features & Benefits

Custom-formed to meet specific requirements
Incoloy®, stainless steel, steel or copper sheath materials available
Superior heat transfer
Available in .315″ and .430″ diameters
Variety of lengths available
USA or global manufacturing options

Our standard lead-time on this product is 15-20 business days. Some expedites available. Consult factory.

APPLICATIONS

PLASTICS
Platen Heaters

PACKAGING
Packaging and Sealing Bars

FOOD SERVICE
Food Grade Sealing/Wrapping
Food Service Warming
Refrigeration

AGRICULTURE
Holding Tanks
Drum & Barrel Heating
Incubators

PROCESS
Textile Processing
Chemical Processing
Laminating Applications
Scientific Testing Equipment
Glass Processing

MORE APPLICATIONS
Deicing
Defrost Heaters
Railway Heating Applications
Medical Process Heaters
Space Heaters for Public Transport

Termination Styles

	Plain Pins Customer can finish termination to suit their application. 5/16â€³ (7.9 mm) pin length is standard.
	Flag Terminals With #10-32 screw. Specify direction.
	Spade Terminals Specify direction of spade terminals.
	Screw Terminal Easy to wire screw terminal with mica washer insulation.
	Bulkhead Fitting Brazed to heater. For quick feed-through mounting. Specify round or hex head, stainless steel or brass.
	Leads High-temperature 250Â° F (121Â° C) lead wire brazed onto the heater terminals. Insulated with fiberglass sleeving and covered with shrink tubing. Specify length of leads.
	Armor Stainless steel armor to prevent abrasion and wear of leads (Type A). Also available with leak-proof bellows. Specify length of leads and armor.

Formations
